Technical specifications

Construction and technical details
Product measurements / dimensions	550x405x640mm 550 x 405 x 870 mm (with coil holder)
product weight	12.9kg
installation space	300x300x400mm
layer height	0.1mm - 0.35mm
print speed	60mm/s - 150mm/s
travel speed	250mm/s
printing surface	tempered glass with coating
heatbed type	AC heated bed
number of extruders	1
filament diameter	1.75mm
supported material	PLA, ABS, Flexible Materials, Wood, PVA, HIPS
calibration	OJ
supply	Titan direct drive extruder
XYZ resolution	0.05mm, 0.05mm, 0.1mm
nozzle type	Volcano
nozzle diameter	0.4mm
nozzle temperature	180 ℃ - 240ºC
Nozzle heating time	< 3 minutes
heating time of the building board	80°C in less than 2 minutes
Build plate temperature max.	130°C
operating noise	< 70dBA
power consumption	100 - 240V 700W max (with the heatbed on)
control board	Artillery Ruby 32
Connection
USB	YES
MicroSD card	YES
USB stick	YES
Shipment
shipping carton	668x508x310mm
shipping weight	16kg
