| Construction and technical details |
|
| Product measurements / dimensions |
550x405x640mm
550 x 405 x 870 mm (with coil holder)
|
| product weight |
12.9kg |
| installation space |
300x300x400mm |
| layer height |
0.1mm - 0.35mm |
| print speed |
60mm/s - 150mm/s |
| travel speed |
250mm/s |
| printing surface |
tempered glass with coating |
| heatbed type |
AC heated bed |
| number of extruders |
1 |
| filament diameter |
1.75mm |
| supported material |
PLA, ABS, Flexible Materials, Wood, PVA, HIPS |
| calibration |
OJ |
| supply |
Titan direct drive extruder |
| XYZ resolution |
0.05mm, 0.05mm, 0.1mm |
| nozzle type |
Volcano |
| nozzle diameter |
0.4mm |
| nozzle temperature |
180 ℃ - 240ºC
|
| Nozzle heating time |
< 3 minutes |
| heating time of the building board |
80°C in less than 2 minutes |
| Build plate temperature max. |
130°C |
| operating noise |
< 70dBA |
| power consumption |
100 - 240V 700W max (with the heatbed on) |
| control board |
Artillery Ruby 32 |
| Connection |
|
| USB |
YES |
| MicroSD card |
YES |
| USB stick |
YES |
| Shipment |
|
| shipping carton |
668x508x310mm |
| shipping weight |
16kg |
